Stainless steel High Pressure Adapter M/M M16x1,5-24° to M18x1,5-24° 2000 bar

The M16x1.5 to M18x1.5 adapter is a stainless steel high pressure fitting for waterjet and industrial cleaning applications. This adapter connects M16x1.5-24° male to M18x1.5-24° male and is designed for a working pressure of 2000 bar.

M16x1.5 M18x1.5 adapter specifications

• Connection A: M16x1.5-24° male
• Connection B: M18x1.5-24° male
• Working pressure: 2000 bar
• Material: martensitic stainless steel
• Standard: DIN 3861

High pressure adapter for waterjet systems

This fitting is manufactured from high-quality martensitic stainless steel. The adapter is suitable for high pressure water systems where reliable sealing, correct thread geometry and mechanical strength are important. The compact design makes the fitting suitable for hose assemblies, pump connections, wall feed-throughs and other high pressure adapter configurations.

Material and engraving

The fittings are produced in accordance with DIN 3861. Standard engraving is supplied with LMT.NL. A customer name can be engraved upon request. For related products, view our high pressure adapter range. More information about DIN standards can be found at DIN.
